150 Degrees Celsius Downhole Cable Well Intervention Armored Cable

Place of Origin	Chongqing, China
Brand Name	Gold
Model Number	GD

Product Details

Product Name:

Geophysical Well Logging Cable

Copper Construction:

19×0.26 Mm

Insulation:

0.35 Mm

Protection:

0.32 Mm

Cable Diameter:

5.60 Mm±0.10 Mm

Cable Weight In Air:

145 Kg/km

Temp Rating:

232 ℃

Cable Breaking Strength:

25 KN

Highlight:

150°C downhole armored cable

well intervention armored cable

geophysical logging high-temperature cable

Product Description

150 Degrees Celsius Downhole Cable Well Intervention Armored Cable

This all-in-one well service cable consolidates seven critical downhole tasks including logging, perforating, and wax removal into a single reliable platform. Its flexible conductor configurations ranging from 7 to 19 strands allow operators to match electrical needs precisely.

Core Strengths

Wide breaking tension range from 8 kN to 110 kN
Consistent 150 degree Celsius rating for thermal stability
Low stretch values as low as 0.7 meters per kilometer

Selection Guide

Following the 80-120 tension guideline ensures safe deployment across varied well depths.

Model	Conductor Build	Diameter (mm)	Breaking Force (kN)	Temp Limit (°C)
WGSB-3.50	7 by 0.21 mm	3.50	8	150
WGSB-5.60	19 by 0.26 mm	5.60	25	150
W7BPP-11.80	7 by 0.32 mm	11.80	85	150
W7BPP-13.20	7 by 0.32 mm	13.20	110	150
